    CatBOSS Manual (SP) – MK60SP EFS for Multihull Vessels

    Single Filter Fuel Management System with Integrated Polishing and Remote Filter Switching

    A Smart Fuel Solution for Each Hull of Your Catamaran

    The CatBOSS Manual (DP) is a multihull-specific fuel management solution based on the proven MK60SP EFS system. Designed for owners who want full-featured, independent fuel protection in each hull, this package equips each engine with its own dedicated filtration, polishing, and monitoring system.

    Unlike more complex cross-feed systems, the CatBOSS Manual keeps things streamlined. Each side is equipped with its own filter, pump, and remote warning panel—giving you everything you need to protect your engines from contaminated fuel without the need for tank interconnection or GSM communication. You get the power and reliability of Keenan Filters’ EFS technology, without the added plumbing.

    Why Choose CatBOSS Manual

    No need for cross-tank plumbing or GSM setup
    Simplifies maintenance and fuel polishing per engine
    Reduces risk of fuel-related engine failure
    Ideal for cruisers, charter operators, or DIY installations
    Easy to install, easy to service, globally supported

    The CatBOSS Manual puts proven Keenan Filters technology into each hull of your multihull vessel—giving you complete control and peace of mind

    GPH (60x2)
    EFS
    Command Panel
    Pump
    Mounting Panel
    Single Switch
    Dual Switch
    Remote Control

    Key Features

    Key Features

    Single MK60SP unit per hull offers independent protection for each engine
    Remote KP300 panel with EFS allows for easy manual filter switching from the cockpit
    Integrated polishing pump cleans and primes fuel before reaching your injectors
    Remote alerts warn of water or clogging before engine performance is impacted
    Top-loading Racor® elements make filter replacement fast and clean
    Durable aluminum and stainless steel construction built for marine environments
    Compact footprint perfect for catamarans, trimarans, and dual-engine sailboats

    What's Included

    System Includes (per hull)

    MK60SP EFS Fuel Management Unit
    Integrated priming and polishing pump
    KP300 Remote Warning Panel with Mute
    KH6010 Interface Box with 15 foot harness
    Polishing Tee Manifold
    All mounting hardware

    Technical Specifications

    Technical Specifications

    Fuel Type: Diesel
    Flow Rate: 60 GPH
    Voltage: 12 VDC
    Current Draw: 2.3 amps
    Water Removal: 99 percent
    Max Pressure: 30 psi
    Operating Vacuum: 0–6 in Hg
    Vacuum Alarm: 8 in Hg
    Water Alarm Capacity: 5.5 oz
    Dimensions: 12.93 in H x 8.26 in W x 6 in D
    Weight: 7.4 lbs
    Ports: 3/4-16 ORB or 1/2 in NPT adapter
    Filter Elements: Racor 2, 10, or 30 micron
    CatBoss Manual (SP) CPMK60-SP-EFS

    $9,000.00

    Does it come with a warranty?

    Yes. All Keenan Filters systems are backed by a limited one-year warranty covering defects in materials or workmanship for the original purchaser. If there’s an issue, we’ll repair or replace the product under warranty terms. We stand behind the quality of our systems and are here to support you.The full warranty details can be found in the installation guide included with your system.

    What if the system isn’t the right fit for my setup?

    Every order is vetted before it ships. Our team speaks directly with each customer to ensure the system is a good match for your vessel and goals. That means you’ll never be left guessing about what you need. If something still isn’t quite right, we’ll support you with troubleshooting, installation guidance, or alternate recommendations. While we don’t offer refunds for installed systems, we’re committed to working with you to find a solution.

    How fast is shipping?

    Most orders ship within 1 week. We use UPS, FedEx, and DHL, depending on your location and shipping needs. If you’re ordering a custom build or have specific delivery requirements, we’ll provide a timeline before processing. Expedited options are available on request.

    What's the returns policy?

    Unused and uninstalled systems may be returned within 30 days of delivery for a full refund, minus shipping. Items must be in original packaging, undamaged, and in resellable condition. Custom or special-order systems are not eligible for return.
